66″ Diameter Hinged Expansion Joints Designed for a Chemical Plant (PT&P Ref#132483)

132483a1



Type: Hinged Expansion Joint
Size: 66″ in diameter and 39-3/8″ OAL
Material: Incoloy 825 / 321 stainless steel
Design 73 psig at 986°F with 4.25 degrees of angular rotation
Testing: Dye Penetrant, X-Ray, PMI, Hydrotest

These single hinged expansion joints were custom designed by U.S. Bellows for a chemical plant in Saudi Arabia. The units are 66″ in diameter and 39-3/8″ OAL. The bellows are fabricated from Incoloy 825 with the weld ends, hinges, liner, and cover from 321 stainless steel. The expansion joints are designed for an operating pressure of 73 psig at 986°F with 4.25 degrees of angular rotation. All units were dye-penetrant tested, X-ray tested on all bellows and pipe longitudinal weld seams, PMI tested on all alloy components, and the alloy steel plate for the pipe was ultrasonic tested prior to shipment. Hinged Pipe Expansion Joints also contain hinges or pivots which allow the unit to bend in a single plane. We’ve supplied this type of expansion joint for both methanol and ammonia plants. They are also used in piping systems for Air, Steam, Gas Turbines, Reformer Ducts, and Burners. These units are designed to restrict axial deflection in extension or compression. The hinge mechanism is typically designed to accept full-pressure thrust. Also, because of the hinge mechanism’s design, shear loads, such as from the weight of adjacent piping, can be accepted by this pipe expansion joint, relieving the piping designer of having to provide additional supports and anchors required by the Single type.

PT&P REF. ORIGINAL POST 06182019
